KHVP Series – High Performance Sliding Vane Vacuum Pumps

Price range: ₹20,000.00 through ₹300,000.00

Parameter Specification
Pump Type Oil Sealed Rotary Vane Vacuum Pump
Stage Single Stage / Double Stage (Model Dependent)
Pumping Speed 20–300 m³/h (Model Dependent)
Ultimate Pressure ≤0.5 mbar (Model Dependent)
Motor Type Direct Coupled Induction Motor
Motor Power 0.75–7.5 kW (Model Dependent)
Supply Voltage 230 V AC, 1 Phase / 415 V AC, 3 Phase
Frequency 50 Hz
Cooling Air Cooled
Rotation Clockwise (Viewing Motor End)
Lubrication Oil Lubricated
Inlet Connection ISO-KF / Flanged (Model Dependent)
Exhaust Oil Mist Exhaust with Separator
Noise Level ≤70 dB(A)
Protection Class IP55
Mounting Horizontal Base Mounted
Duty Cycle Continuous Duty (S1)
Construction Heavy Duty Cast Iron Housing
Applications Vacuum Drying, Distillation, Degassing, Vacuum Furnaces, Freeze Drying, Vacuum Packaging, Laboratory & Industrial Processes

DOWNLOAD CATALOGUE

SKU: N/A Category: Brand:

Description

Product Description

The Oil Sealed Rotary Vane Vacuum Pump is designed for reliable, continuous-duty operation in laboratory, industrial, pharmaceutical, chemical, vacuum coating, metallurgy, and research applications. Precision CNC-machined components ensure excellent dimensional accuracy, low vibration, reduced noise, and long service life. The pump delivers high pumping efficiency with a low ultimate pressure, making it suitable for demanding vacuum processes requiring stable and consistent performance. Its rugged construction, efficient oil circulation system, and replaceable internal components provide easy maintenance and dependable operation even under continuous use.

Reviews

There are no reviews yet.

Be the first to review “KHVP Series – High Performance Sliding Vane Vacuum Pumps”

Your email address will not be published. Required fields are marked *

Additional information

Dimensions N/A
Model KHVPC

KHVPC-2, KHVPC-4, KHVPC-8, KHVPC-16, KHVPC-30, KHVPC-60, KHVPC-90

Model KHVPS

KHVPS-2, KHVPS-4, KHVPS-8, KHVPS-16, KHVPS-30, KHVPS-60, KHVPS-90
